360° Megapixel Camera

Product Features

A newly developed fisheye lens

Equipped with a small-sized fisheye lens (φ20mm), taking pictures in hemispheric field of vision can reduce number of cameras to use.
Ultra wide angle lens with a dpression angle of 17°(World largest view angle 214 °) expands the use application of 360° camera.
Because of the fisheye lens feature, focusing and angle adjustment is not necessary.

Ultra Wide Angle View

It's relatively near the view of human eyes, and you can take a picture with secure feelings.
You can convert a hemispheric image to a flat image and can zoom or scroll any portion of the images.

No Pan-Tilt mechanism

Elimination of the swinging mechanism has reduced its cost and risk of malfunction but gotten superior durability.

Movie to intriduce the 360° camera function

Applications

Useful for surveillance or crime prevention camera system and the TV meeting system.
Because of its small size, good for robot, machine installation.

Presentation Download





Products Line-up(Clicking a product name can open its catalogue.)



Examples of Application(Clicking a color changeable picture will show a detail description (in Japanese).)

TV会議システム映像取込装置
Camera for TV Conference
災害現場探査ロボット
Crime Sceen Robot
生活支援ロボット
Tokyo University
Life Support Robot
ATM
顔認証システム
Face Recognition System
中国上海市地下鉄車両内カメラ
Chine Sub-way Car
駐車場
Parking Space
バス車内カメラ
Bus
店舗
Shop
コンビニエンスストア
Convenience Store
不法投棄監視
Illegal Dump place
車上カメラ
Car Roof Top Camera
事務所
Office
工事現場
Construction Site
工場内
Factory





Example of Video Image(Clicking a product name can open its catalogue.)

Car Roof Top Camera 1(MPEG4 image)

An example of video image taken by a Car Roof Top Camera NM33-M (w/depression angle lens) built-in.
Video taken by the original application software in the 180 degree panorama x2 mode.
The front 180° image is indicated in the upper half of the display and the rear 180° image is in the lower half.
Frame rate : approx. 6~10fps

Note: Animation to combine the scenes belongs to the Windows Movie Maker.

POINT!
Distant mountains are clearly visible.
  With our original lens with depression angle, 17°below the lens level is in the view.

Car Roof Top Camera 2(MPEG4 image)

An example of video image taken by a Car Roof Top Camera NM33-M (w/depression angle lens) built-in.
Video taken by the original application software in the 180 degree panorama x2 mode.
The front 180° image is indicated in the upper half of the display and the rear 180° image is in the lower half.
Frame rate : approx. 6~10fps

Scene 1: Highway: Running at about 90km/h backed by the setting sun.
Scene 2: Tunnel
Scene 3: Tokyo city area: Display mode was switched. Car-left image is shown in the upper half and the car-right image is in the lower half.


Installing in the car(MPEG4 image)

NM33-M is installed beside the room miller facing downwards in a car.
Video taken by the original application software in the 180 degree panorama x2 mode.
The front outside 180° image is indicated in the upper half of the display and the car-inside 180° image is in the lower half.
Frame rate : approx. 6~10fps

POINT!

The exposure of the outside/blight and the inside/dark are simultaneously well controlled, regardless they are takes by a lens.
Our original patentable technology

Non-dewarped image(MPEG4 image)

Taken in the Large mode.
Optional software (Refinder) is required to dewarp the non-dewarped image taken in the Large mode.
The frame rate of the video taken in the Large mode os approx. 3fps.


Note: The image resolution of the above example videos defer from the original camera image due to the U-Tube(MPEG4) formatting.
